Buy Mild Steel Plates at affordable price from us. ASME SA 36 Mild Steel Sheets is the use of innovative technology and strong emphasis on quality control, which provides these products high durability. ASME SA 36 Mild Steel Coils also offers some excellent features such as timely rendered, use of superior quality components, offered as per client’s specification and more. ASME SA 36 MS Plates have a team of professionals, which renders these services in tandem with the guidelines laid in the industry to attain highest benchmarks of quality.

Inquiry
Categories: ,
Description
Specifications : ASTM A36 / ASME SA36
Standard : AISI, ASTM, BS, DIN, GB, JIS
Thickness : 0.5-100mm
Specialize : Shim Sheet, Perforated Sheet, B. Q. Profile.
Length : 2000-12000 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange)
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Grade : MS A36, (UNS K02600)

Mild Steel A36 Plates Equivalent Grades

STANDARD WERKSTOFF NR. UNS
MS A36 50049 3.1 K02600

A36 Mild Steel Plates Chemical Composition :

Grade C Cu Fe Mn P Si S
A36 min. 0.25 – – – – – –
max. 0.290 0.20 98.0 1.03 0.040 0.280 0.050

ASTM A36 Plates Mechanical Physical properties:

Grade Properties Metric Imperial
A36 Density 7.85 g/cm3 0.284 lb/in3
Tensile Strength, Ultimate 400 – 550 MPa 58000 – 79800 psi
Tensile Strength, Yield 250 MPa 36300 psi
Elongation at Break (in 200 mm) 20.0 % 20.0 %
Elongation at Break (in 50 mm) 23.0 % 23.0 %
Modulus of Elasticity 200 GPa 29000 ksi
Bulk Modulus (typical for steel) 140 GPa 20300 ksi
Poissons Ratio 0.260 0.260
Shear Modulus 79.3 GPa 11500 ksi
