Specification of C11000 Copper Bar
Standard & Material
|
CDA 110 ETP, ASTM B124, ASTM B152, ASTM B187, ASTM B188, ASTM B272
|
HOLLOW RODS
|
Min Bore Size 20 mm and Max OD 100 mm
|
ROUND RODS
|
8mm To 100 mm
|
HEX
|
10mm To 60mm
|
SQUARE
|
10mm To 60mm
|
FLAT
|
10mm Min Thickness and max Width 120mm
|
BILLETS
|
Up to 200 mm
|
INGOTS
|
As per Specification
|
Applications of C11000 Copper Bar
- Architectural Industry
- Antimicrobial Applications
- Electrical Industry
- Telecommunications Industry
Equivelent Specifications of C11000 Copper Bar
End Product
|
Specification
|
Bar
|
ASME SB133, ASTM B152, SAE J461, J463
|
Bar, Bus
|
ASTM B187
|
Bar, Forging
|
ASTM B124
|
Rod
|
ASME SB133, MILITARY MIL-C-12166, SAE J461, J463
|
Rod, Bus
|
ASTM B187
|
Chemical Composition of C11000 Copper Bar
Element
|
Content (%)
|
Cu
|
99.90
|
Physical Properties of C11000 Copper Bar
Properties
|
Metric
|
Imperial
|
Density
|
8.89 g/cm3
|
0.322 lb/in3
|
Melting point
|
1065 – 1083°C
|
1949°F
|
Mechanical Properties of C11000 Copper Bar
Properties
|
Metric
|
Imperial
|
Hardness, Rockwell F (hard temper)
|
80.0
|
80.0
|
Poisson’s ratio
|
0.34
|
0.34
|
Elastic modulus
|
115 – 117 GPa
|
16969 ksi
|
Fabrication of C11000 Copper Bar
Joining Technique
|
Suitability
|
Brazing
|
Good
|
Butt Weld
|
Good
|
Capacity for Being Cold Worked
|
Excellent
|
Capacity for Being Hot Formed
|
Excellent
|
Coated Metal Arc Welding
|
Not Recommended
|
Forgeability Rating
|
65
|
Gas Sheilded Arc Welding
|
Fair
|
Machinability rating
|
20
|
Oxyacetylene Welding
|
Not Recommended
|
Seam Weld
|
Not Recommended
|
Soldering
|
Excellent
|
Spot Weld
|
Not Recommended
|
